Products > Veneer Clipper > Veneer Rotary Clipper > Veneer Rotary Clipper

Product name : Veneer Rotary Clipper

Item : BJG1326

Enlarge Image

Back

Details:

Rotary Clipper Machine Model	BJG1326	BJG1320	BJG1313
Max. working width	2650	2100	1450mm
Veneer shearing Knife blade length	2700mm	2150
Standard knife blade quantity	3pcs (1set)	3pcs (1set)	3pcs (1set)
Anvil diameter	398mm	398mm	398mm
Max. sheering linear velosity	100m/min	100m/min	100m/min
Feed speed (m/min)	100m/min	100m/min	100m/min
Feed motor power	3.7kw (servo motor)	3.7kw(servo motor)	3.7kw (servo motor)
Cutting motor power	11kw (servo motor)	7.5kw(servo motor)	7.5kw (servo motor)
Overall dimension (including veneer convery section)	5950×3860×1740	5950×3430×1740	5950×2660X1680mm
Weight	3500	3200kg	3050kg

Following it on Facebook

Veneer Rotary Clipper Serious Machines Europe CE Certification Available.
